    50mm 60mm Mini Drill Rigs Underground Crawler With Air Compressor

    Ask Lasest Price
    Brand Name : Tytion
    Model Number : TY-100
    Certification : CE, SGS
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 150 sets per month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    50mm 60mm Mini Drill Rigs Underground Crawler With Air Compressor

    Underground crawler mini Drill Rigs For Sale with air compressor


    Drill Rigs For Sale


    Structure of Drill Rigs For Sale:

    The drill rigs tool consists of drill pipe, ball tooth bit and impactor. When drilling, use two drill pipe joints to drill. The rotary air supply mechanism is composed of rotary motor, rotary reducer and rotary air supply. The rotary reducer is a kind of three - stage cylindrical gear closed heterotropic component, which is automatically lubricated by screw oiler. The air supply rotary is composed of a connecting body, a seal, a hollow spindle and a drill pipe joint, etc., on which is provided with a pneumatic clamp for connecting and unloading drill pipe. Lifting pressure regulating mechanism is by lifting motor with the help of lifting reducer, lifting chain, and the rotary mechanism and drilling tools to achieve lifting action. In the closed chain system, a pressure regulating cylinder and a moving pulley group are provided. In normal operation, the piston rod of the pressure regulating cylinder drives the pulley group to make the drilling tool realize decompression drilling.


    Parameters of Drill Rigs For Sale:

    ModelTY-100
    Max. propelling force9600 N
    Rated speed1440 r/min
    Drill pipe outer diameter50-60 mm
    Drill rod length1025 mm
    Weight470 kg
    Machine size2280*440*500 mm

    Features of Drill Rigs For Sale:

    1. Mechanical transmission, hydraulic feed, the output efficiency of the whole machine is more than 95%;

    2. Compact structure, reasonable connection design, can be divided into motor, rotary, gear box winch, frame control mechanism four parts, simple disassembly, convenient assembly;

    3. Hydraulic chuck design, simple operation can achieve easy conversion of 360 degrees drilling.


    Pictures of Drill Rigs For Sale:

    50mm 60mm Mini Drill Rigs Underground Crawler With Air Compressor


    Quality 50mm 60mm Mini Drill Rigs Underground Crawler With Air Compressor for sale
